Network Cables

This range of booted Cat5e RJ45 Ethernet Cables/Patch Leads are manufactured and tested to conform to the ISO11801 Cat5 1999 and EIA/TIA 568 Addendum 11 draft standards for enhanced performance. Each Cat5e RJ45 Ethernet Cable consists of 4 colour coded pairs. The PVC outer sheath and the stranded cores results in a high flexible and resilient cable.

All Proposed Category 5e Requirements as per ANSI/TIA/EIA, ISO/IEC and CENELEC Standards

1. ANSI/TIA-568-C.2
2. ISO/IEC 11801 Channel Class D
3. CENELEC EN 50173-1
4. CENELEC EN 50288
RoHS Compliant for European Union Issued Directive 2002/95/EC

Features:
Guaranteed performance to 125MHz
Superior cable flexibility from stranded cores
Boot maintains correct bend radius to ensure maximum performance
Connector: 8P8C, RJ45, 50 inch gold plating
ANSI/TIA 568 C.2 T568B pinout termination
Flame Retardancy is verified according to IEC 60332-1-2
RoHS compliant

The moulded boot offers strain relief to the cable helping prevent the cable being pulled free from the RJ45 plug, and its flush design means it can easily be used in high density installations. Available in a wide choice of colours and lengths up to 30mt, Comms Express are the business to business specialists, delivering great savings on top manufactured booted RJ45 patch leads.

Applications:
1000BASE-TX / 1000BASE-T Gigabit Ethernet
100BASE-TX Fast Ethernet
10BASE-TX Ethernet
Booted RJ45 ethernet cables/patch leads are essential to effective business operations. Together with patch panels and switches they play an integral role in network communications, providing connection for Ethernet, ISDN, and VoIP phones systems. Quality and reliable booted RJ45 cat5e patch leads are the glue which holds networks together.

Our range of Cat6 RJ45 Ethernet Cable/Patch Leads are manufactured and tested to conform with all the necessary standards for Cat6 communications.

All Proposed Category 6 requirements as per ANSI/TIA, ISO/IEC and CENELEC EN Standards

1. ANSI/TIA-568-C.2
2. EN 50173 Channel Class E
3. IEC 61935-2 for Patch Cord
4. ISO/IEC 61156-6end Edition for Stranded Cable
RoHS Compliant for European Union Issued Directive 2002/95/EC

Features:

Guaranteed performance to 250MHz
The particular saw-tooth design of jacket towards inner can enhance the resistance of alien crosstalk
The unique design of PE cross reduces the NEXT and RL ,and provides better transmission.
Superior cable flexibility from stranded cores
Boot maintains correct bend radius to ensure maximum performance
Connector 8P8C, RJ45, 50 inch gold plating
ANSI/TIA 568 C.2 T568B pinout termination
Flame Retardancy is verified according to IEC 60332-1-2.
RoHS compliant
Each lead is made with high quality Cat6 plugs, highly flexible PVC sheath and stranded copper conductors. Between the cable and plug is a boot to provide strain relief and protection to the cable.  The low profile design of the boot means it's ideal for use in high density installations.

Applications:


10GBASE-T Ethernet
1000BASE-TX/ 1000BASE-T Gigabit Ethernet
100BASE-TX Fast Ethernet
10BASE-TX Ethernet
This range is available in a wide variety of colours and lengths up to 20mt (30mt in White).

Category 6a Ethernet Cable/Patch Leads – Augmented Category 6 – cables, and associated connectors, take the performance capabilities of copper infrastructure to new levels. Designed to the current ISO and EIA/TIA standards for Class Ea augmented Category 6a performance these products are intended to deliver reliable, high network performance including support of emerging applications such as 10GBase-T, 10 Gigabit Ethernet.
Each Category 6a patch leads consists of 4 twisted pairs of 26AWG stranded copper wires, an aluminium/polyester foil tape provides an individual screen for each pair. These pairs are then cabled together, with different lay lengths to ensure optimum performance. Staggered pin RJ45 shielded plugs, terminate the cable, and each lead is fitted with colour coded slimline molded boots, suitable for use in high density router or switch blades.

Performance Overview
Category 6A patch leads are designed, manufactured and tested in accordance with the ISO and TIA standards for Cat 6A. The use of foil tape screens in the design of this cable ensure that systems are immune to performance concerns sometimes found in high speed, high frequency copper cable networks. Cables designed with pair screening such as this act against Alien Crosstalk, the inducement of noise from one 4 pair cable to an adjoining cable as well as protecting against signal loss though emissions and enabling immunity from disturbance’s which could potentially be received from external sources.

Features:

Specified to 500MHz
Suitable for 10 Gigabit, 10GBase-T, Ethernet application
Individual foil screen over each pair
Blade style molded strain relief boot with clip protector
Choice of Length and Colour
Low Smoke Zero Halogen Outer Sheath

CE's Cat5e UTP Patch Cable is a stranded Cat5e cable for manufacturing patch cables. This cable is Cat5e compliant, It has a standard conductor for patch leads and comes in various colours.

Each cable consists of 8 colour coded polyethylene insulated conductors. These are twisted together to form 4 pairs and jacketed in a heat resistant PVC material. ETL/3P certified and tested to meet  ANSI/TIA 568C.2 Category 5e safety/performance requirements.

Features: Available in 100mtr reels
Stranded Cat5e cable for manufacturing patch cables
Cat5e 4 pair UTP PVC patch cable with 8 colour coded polyethylene insulated conductors.
Available in ten colours
Supports Gigabit Ethernet
Manufactured and tested to the ISO 11801, EN 50173 & ANSI/TIA-568-C standards
Material & Construction Conductor Materials Bare Copper Size 24 AWG Insulation Materials HDPE Colour Blue/White Orange/White Green/White Brown/White Jacket Materials Flame Retardent PVC Diameter Nominal 5.2 mm Colour Various Construction U/UTP No. of Pairs 4 Category 5e Number of Cores 8



Configuration Orange 2 Green 3 White/Orange White/Green Blue 1 Brown 4 White/Blue White/Brown

Accessories
(sold Separately)

Tools

Universal Stripping Tool Crimp Tool

RJ45 UTP Inline Coupler

The inline coupler is ideal for the extension of existing cabling installations, offering a straight through RJ45 to RJ45 connection while maintaining cat5e performance.

RJ45 IP67 rated waterproof CAT5E/CAT6 external cord coupler - UTP/FTP
Ideal for CCTV, signage, stadiums, POE lighting, office buildings and all external situations
Shielded design and so ideal for shileded and non-shielded plugs with or without boots
Extra space for different size plug boots and so will accommodate most plug designs
Female to female coupling, can use on suitable pre-terminated cords if required
UL94V0 flame retardant plastic along with Anti-UV properties
Designed for outdoor use on buildings and homes where ingress of water may be an issue. Enabling the joining of two RJ45 terminated external cables specified as CAT5E or CAT6. CAT6 specifies performance characteristics for frequencies up to 250MHz and backwards compatible with CAT5E

Pin out schematic

RJ45 RJ45 Pin Pin 1 to 1 2 to 2 3 to 3 4 to 4 5 to 5 6 to 6 7 to 7 8 to 8

The RJ45 plug lock-in device is an innovative solution that secures connections to reduce network downtime, data security breaches, and hardware replacement due to theft. The versatile design works with most existing patch cords, faceplates, patch panels, IP cameras and other IP devices. It is also compatible with VoIP phones helping to prevent unauthorized removal and ensure E911 continuity.







Features and Benefits

Flat - for use with Patch Panels
Recessed - for use with RJ45 Wall Modules/Outlets
Tamper-resistant - Prevents unauthorized removal of cable, IP phone, other networking equipment or critical connection; compatible with VoIP phones to deter unauthorised users from moving or stealing phones, helping maintain E911 availability and compliance
Compact design - Can be installed without interfering with adjacent jacks and plugs, even in high-density applications
Installation/Removal Tool - Allows plug to be locked into or released from jack for enhanced physical security
Colour assortment - Available in Red and Black

RJ45 UTP Cat5e 8 Way Plug

50 Micron 8P8C RJ45 Connectors sold in packs of 100, for use in UTP (unshielded) Cat5e applications.

Available in 6 lengths from 0.6 m to 4.9 m

Features:

Black PVC sheath
Part number and length printed on the boot
Compatible with colour coded PatchClips for the first level of identification
A reliable patch cord for all networks:

Conforms to EIA/TIA 568-B2.2-1 category 5e
100% testing of electrical and optical properties
Each patch cord identified by a unique serial number
How it works

Available in 6 lengths from 0.6 m to 4.9 m

Features

Black sheath
Grey boot to distinguish it from black booted category 5e patch cords
Part number and length printed on the boot
Compatible with colour coded PatchClips for the first level of identification
A reliable patch cord for all networks:

Conforms to EIA/TIA 568-B2.2-1 category 6
25 year guarantee for use in category 6 channels interoperable with any cabling system= quality control :  100% testing of electrical and optical properties
Test results saved onto a database
Each patch cord identified by a unique serial number
Plastic cross web unshielded (UTP) and individually foil shielded pairs (FTP)
PVC sheath for UTP cables and zero halogen (LSOH) sheath for FTP cables


How it works
